KAC-KHI-0.25/6(500pc)

Patch cable SC-Isopod SO-F22; 2 x 0,22 mm²; PVC Ø 3,30 mm; orange

Technical Data: - Properties: Analog - Properties: OFC oxygen free copper - Application area: Installation - Application: Patch cable - Colour: orange - Colour detailed: orange - Signal transmission: symmetrical - Jacket material: PVC - Jacket Ø: 3,3 mm - Number of Channels (audio): 1 - Inner conductor (audio): 2 - Inner conductor (audio): 0,22 mm² - Inner conductor Ø (audio): 0,53 mm - AWG (audio): 24 - Shielding: AL / PT foil + AL / PT foil + filler strand, tin-plated - Copper strands (audio): 7 - Copper strand Ø (audio): 0,20 mm - Conductor insulation material: PE - Conductor insulation Ø: 1,12 mm - Weight per 1 m: 16 g - Fire load per m: 0,05 kWh - Style variant: round - Shielding factor: 100 % - Packing: 200 m spool - Temperature min.: -25 °C - Temperature max.: 70 °C - Width: 3,3 mm - Height: 3,3 mm - Capac. cond./cond. per 1 m (audio): 74 pF - Capac. cond./shield. per 1 m (audio): 143 pF - Insulation resist. per 1 km: 0,2 GΩ - Insulation resist. per 1 km (audio): 0,2 GΩ - Conductor resistance per 1 km: 88 Ω - Shield. resistance per 1 km: 75 Ω Only available on full 200m lenghts

Patch cable SC-Isopod SO-F22; 2 x 0,22 mm²; PVC Ø 3,30 mm; grey

Technical Data: - Properties: Analog - Properties: OFC oxygen free copper - Application area: Installation - Application: Patch cable - Colour: grey - Colour detailed: grey - Signal transmission: symmetrical - Jacket material: PVC - Jacket Ø: 3,3 mm - Number of Channels (audio): 1 - Inner conductor (audio): 2 - Inner conductor (audio): 0,22 mm² - Inner conductor Ø (audio): 0,53 mm - AWG (audio): 24 - Shielding: AL / PT foil + AL / PT foil + filler strand, tin-plated - Copper strands (audio): 7 - Copper strand Ø (audio): 0,20 mm - Conductor insulation material: PE - Conductor insulation Ø: 1,12 mm - Weight per 1 m: 16 g - Fire load per m: 0,05 kWh - Style variant: round - Shielding factor: 100 % - Packing: 200 m spool - Temperature min.: -25 °C - Temperature max.: 70 °C - Width: 3,3 mm - Height: 3,3 mm - Capac. cond./cond. per 1 m (audio): 74 pF - Capac. cond./shield. per 1 m (audio): 143 pF - Insulation resist. per 1 km: 0,2 GΩ - Insulation resist. per 1 km (audio): 0,2 GΩ - Conductor resistance per 1 km: 88 Ω - Shield. resistance per 1 km: 75 Ω Only available on full 200m lenghts

Speaker Cable Elephant SPM425; 4 x 2,50 mm²; PVC Ø 10,20 mm; black

Technical Data: - Properties: Analog - Properties: OFC oxygen free copper - Application area: ELA 100 V - Application area: Studio / Broadcast - Application area: Stage / live - Application area: Mobile outdoor / indoor - Application area: Installation - Application: Speaker Cable - Colour: black - Colour detailed: black - Jacket material: PVC - Jacket Ø: 10,2 mm - Number of Channels (audio): 1 - Inner conductor (audio): 4 - Inner conductor (audio): 2,5 mm² - Inner conductor Ø (audio): 1,78 mm - AWG (audio): 13 - Copper strands (audio): 78 - Copper strand Ø (audio): 0,20 mm - Conductor insulation Ø: 3,05 mm - Weight per 1 m: 180 g - UV-resistant: yes - Fire load per m: 0,80 kWh - Style variant: round - Packing: bulk stock - Temperature min.: -25 °C - Temperature max.: 70 °C - Width: 10,2 mm - Height: 10,2 mm - Insulation resist. per 1 km: 0,005 GΩ - Insulation resist. per 1 km (audio): 0,005 GΩ - Conductor resistance per 1 km: 7,7 Ω - Test voltage: 2000 V

19" Housing for Fuse Switches

Product type 19" Rack Accessories Colour Black Material sheet steel Surface powder coated Height 3 U Cut out 430 x 46 mm Weight 1,15 kg

Declaration of Conformity
