NEU-BTXX

SC-Monolith 4 HV; power: 3 x 2,50 mm²; DMX: 2 x 0,25 mm²; PVC Ø 18,00 mm - Power OD: 8,3mm; black

Technical Data: - Name: SC-Monolith 4 HV - Properties: Digital 110 Ω AES / EBU - Properties: Analog - Properties: OFC oxygen free copper - Application area: Installation - Application area: Studio / Broadcast - Application area: Stage / live - Application area: Mobile outdoor / indoor - Application: DMX & Power - Colour: black - Colour detailed: black - Signal transmission: symmetrical - Jacket material: PVC - Jacket Ø: 18 mm - Jacket Ø (power): 8,3 mm - Jacket Ø (AES/EBU, DMX): 4,3 mm - Number of Channels (power): 1 - Number of Channels (AES/EBU, DMX): 4 - Inner conductor (power): 3 - Inner conductor (AES/EBU, DMX): 2 - Inner conductor (power): 2,5 mm² - Inner conductor (AES/EBU, DMX): 0,25 mm² - Inner conductor Ø (power): 1,78 mm - Inner conductor Ø (AES/EBU, DMX): 0,56 mm - AWG (power): 13 - Shielding (AES/EBU, DMX): Braided mesh, tin-plated - Copper strands (power): 48 - Copper strands (AES/EBU, DMX): 7 - Copper strand Ø (power): 0,25 mm - Copper strand Ø (AES/EBU, DMX): 0,20 mm - Wire insulation material (power): PVC - Conductor insulation Ø (power): 3,1 mm - Weight per 1 m: 376 g - UV-resistant: yes - Fire load per m: 1,24 kWh - Style variant: round - Shielding factor: 90 % - Packing: bulk stock - Temperature min.: -30 °C - Temperature max.: 70 °C - Width: 18 mm - Height: 18 mm - Capac. cond./cond. per 1 m (AES/EBU, DMX): 52 pF - Capac. cond./shield. per 1 m (AES/EBU, DMX): 89 pF - Surge impedance (AES/EBU, DMX): 110 Ω - Insulation resist. per 1 km (AES/EBU, DMX): 0,1 GΩ - Conductor resistance per 1 km (power): 80 Ω

Road line cont Female gold 150

This original Syntax component is provided with a protective jacket to improve contactation on SHD series connector. Improved electrical conductivity Self-centered for a seamless connection. Lower operating temperature Increased number of mating cycles

Road line cont Male gold 150

This original Syntax component is provided with a protective jacket to improve contactation on SHD series connector. Improved electrical conductivity Self-centered for a seamless connection. Lower operating temperature Increased number of mating cycles

Nylon Braid, black for cable diam 3-8mm (100m)

Features

• Flame-retardant
• Halogen-free
• Durable abrasion resistance in a wide range of industrial applications

Application

Polyester expandable sleeving is used where mechanical protection is required, such as cables, wire harnesses, tubes and industrial hoses. The open weave construction allows for ease of use when bundling cables and hoses, even those with large or bulky connectors. Totally expanded, the sleeving can reach at least one and a half times its initial dimension.
