NEU-NAUSB3

Male cable rubber

Volrubber contactstop 16A, 250V~ 2 polig met bus- en randaarde
(conform NEN 1020 en NBN C 61-112-1).

kleur : zwart
gewicht : 120 g

Eigenschappen:

• slijtvaste, olie- en zuurbestendige massief rubber mantel
• ontwikkeld voor zwaar industrieel gebruik
• zeer drukbestendig, vormvast rubber binnenwerk
• montagevriendelijk door wegklapbare trekontlasting
• vernikkelde contacten
• schroeven met kombi-kop
• reeds geopende contacten
• IP44 stof- en spatwaterdichte kabelinvoer
• geschikt voor neopreenkabel van 3 x 2,5 mm²

Isolated BNC chassis connector, feedthrough in nickel D-shape housing

Isolated BNC chassis connector, feedthrough in nickel D-shape housing Neutrik's BNC chassis connectors offer a true 75 ? design for serial and digital (HD) signals. The machined brass connector body provides an extremely rugged and non-abrasive connection over long term use and is in addition recessed and therefore well protected in a D-shape housing (audio industry standard). Features & Benefits •Gold plated cage type center contact •True 75 ? design meets the stringent HD requirements •Isolated panel mount (solves potential grounding problems and prevents common-mode influence with other connections conducted over the same panel ground potential) •Standard D-shape housing - provides flush mounting and protection from demage •Color coding possible New cage type contact •Closed contact design - extremely robust •Gold plated cage type clip - best possible shielding and lowest contact resistance

etherCON CAT6_A cable connector self-termination, nickel plating

etherCON CAT6A cable connector self-termination, for insulation diameter > 1.1 mm, nickel plating The set NE8MX6 consists of a cable plug carrier offering a robust metal shell, proven Neutrik chuck-type strain relief and a CAT6A compliant RJ45 plug. The set is suitable for a cable diameter range of 7 mm to 9.5 mm and wire gauge of AWG26/1 - AWG22/1 (solid) or AWG27/7 - AWG22/7 (stranded). Attention! Does not intermate with the CAT6 chassis connectors NE8FDY-C6 and NE8FDY-C6-B. Features & Benefits •Ruggedized connector with CAT6A component compliance according to ISO/IEC 11801 and TIA/EIA 568-C.2 •PoE+ compliant according to 802.3at Type2 •IP65 protected when mated with NE8FDX-P6-W or NE8FDX-Y6-W •Rugged latch lock system million fold proven •Intermateable with the existing etherCON CAT5 range •Unique Neutrik chuck-type strain relief

Grounded BNC chassis connector, feedthrough in nickel D-shape housing

Grounded BNC chassis connector, feedthrough in nickel D-shape housing Neutrik's BNC chassis connectors offer a true 75 ? design for serial and digital (HD) signals. The machined brass connector body provides an extremely rugged and non-abrasive connection over long term use and is in addition recessed and therefore well protected in a D-shape housing (audio industry standard). Features & Benefits •Gold plated cage type center contact •True 75 ? design meets the stringent HD requirements •Grounded panel mount •Standard D-shape housing - provides flush mounting and protection from demage •Color coding possible New cage type contact •Closed contact design - extremely robust •Gold plated cage type clip - best possible shielding and lowest contact resistance
