NEU-NLT4MPXX-BAG

SPEAKER CABLE - 8 x 2.5mm² - OD: 14mm

This range of SYNTAX® SPEAKER cables has been developed to obtain maximum flexibility and excellent mechanical properties. The main characteristic is the extremely dense stranding of the conductors’ section, which results in high flexibility, increased conductivity and brilliance of sound. They feature large conductor size to minimize resistance to high power conduction. All the conductors are numbered and maintained properly clustered inside the outer PVC sheath thanks to the internal lined ridges, even under heavy usage and continuous rewinding. The cores are talc dusted to slide against one another, thus granting optimal handling. The external diameters is perfectly suitable for usage with the most commonly used power connectors. Finally, the arctic polymer PVC jacket allows good flexibility and handling in a wide range of temperatures.

Speaker Cable Elephant SPM425; 4 x 2,50 mm²; PVC Ø 10,20 mm; black

Technical Data: - Properties: Analog - Properties: OFC oxygen free copper - Application area: ELA 100 V - Application area: Studio / Broadcast - Application area: Stage / live - Application area: Mobile outdoor / indoor - Application area: Installation - Application: Speaker Cable - Colour: black - Colour detailed: black - Jacket material: PVC - Jacket Ø: 10,2 mm - Number of Channels (audio): 1 - Inner conductor (audio): 4 - Inner conductor (audio): 2,5 mm² - Inner conductor Ø (audio): 1,78 mm - AWG (audio): 13 - Copper strands (audio): 78 - Copper strand Ø (audio): 0,20 mm - Conductor insulation Ø: 3,05 mm - Weight per 1 m: 180 g - UV-resistant: yes - Fire load per m: 0,80 kWh - Style variant: round - Packing: bulk stock - Temperature min.: -25 °C - Temperature max.: 70 °C - Width: 10,2 mm - Height: 10,2 mm - Insulation resist. per 1 km: 0,005 GΩ - Insulation resist. per 1 km (audio): 0,005 GΩ - Conductor resistance per 1 km: 7,7 Ω - Test voltage: 2000 V

Panel 3 pole Female, Black housing, silver contacts, D-size

Panel 3 pole Male, Black housing, silver contacts, D-size

3 pole male receptacle, solder cups, black metal housing, silver contacts The DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding. It is the ideal match for mating with Neutrik's EMC XLR cable connector. Features & Benefits •All metal housing offers best overall RF protection and electromagnetic shielding •Duplex ground contact for excellent contact integrity between chassis and cable connector •Male connector's retention bar replaces plastic design with all metal version improving pull-out force •Larger solder contacts for easier termination •Optional connection to easily join pin1 to chassis ground •D-style housing provides installation compatibility with industry standard D mounting dimensions
