NEU-SCCD-W

SPEAKER CABLE - 4 x 2.5mm² - OD: 10,5

This range of SYNTAX® SPEAKER cables has been developed to obtain maximum flexibility and excellent mechanical properties. The main characteristic is the extremely dense stranding of the conductors’ section, which results in high flexibility, increased conductivity and brilliance of sound. They feature large conductor size to minimize resistance to high power conduction. All the conductors are numbered and maintained properly clustered inside the outer PVC sheath thanks to the internal lined ridges, even under heavy usage and continuous rewinding. The cores are talc dusted to slide against one another, thus granting optimal handling. The external diameters is perfectly suitable for usage with the most commonly used power connectors. Finally, the arctic polymer PVC jacket allows good flexibility and handling in a wide range of temperatures.

Cable Speakon [10-16mm] - 4P , Female

4 pole speakON cable connector, screw terminal assembly, chuck type strain relief for cable diameters 10 to 16 mm

speakON connectors are the industry-standard for loudspeaker connections. This product series offers extremely reliable and robust cable connectors with a proven twist lock system. speakON cable connectors feature solid contacts with screw-type terminals including a stranded wire protection.

Features & Benefits

Female cable SCHUKO 16A/230V BLACK (Special: DE/NL standard) + cover - No child protect clips

Order number 7488
EAN/pcs 4024941854030
Product Group Domestic connector with MULTI-GRIP cable gland
Amperage 16A
Poles 3p (2P+PE)
Voltage 250V
Frequency alternating current (AC)
Protection IP54
Color code black RAL 9005
Connection Design head-Screw Terminal
Max. conductor 4,0 mm²
Further Information
Additional technical information With child protection (Shutter)
MULTI-GRIP cable gland with gasket and integrated strain relief
With self-closing hinged lid
Material
Material of Enclosure Polyamide
Contact / Contact Carrier contact carrier made of Polyamide, contacts are brass nickel plated
Weight/pcs 0.093 kg
Packaging unit 20 pcs

Declaration of Conformity

Panel CAT5e feedthrough, D-shape, Black housing

RJ45 feedthrough receptacle, black D-shape metal flange with the latch lock, mounting screws included The etherCON Series is a ruggedized and lockable RJ45 connector system, optimized for pro audio, video and lightning network applications. The chassis connectors are shaped to fit into standardized panels out of the entertainment industry. The D-Series offers the most rugged design of the etherCON series and is perfectly suitable for panel mount and the installer market. Attention! Does not intermate with CAT6 cable connector NE8MC6-MO and NKE6S* cables. Features & Benefits •Accommodates NE8MC* or any standard RJ45 plug •Approved latch lock system •Mountable from the front or rear of the panel •Complies with Cat 5e according to TIA / EIA 568B and ISO / IEC 11801 standard
