BNC krimpconnector type J01000A0059
BNC Straight Plug Crimp RG 213/U crimp/crimp
The BNC series is the most commonly used coax connector. With its bayonet coupling mechanism this connector can be used up to 4 GHz. Both 50 and 75 ? impedances are available. Connector styles are available for flexible, conformable and semi-rigid cable types. Versions of the BNC connector are available for mounting to printed circuit boards using both through-hole soldered and through-hole press-fit techniques. Both crimp and clamp cable termination processes are used for this series. BNC connectors are used for signal, data and video transmission applications.
| Contact resistance inner conductor |
≤ 20 m? |
| Contact resistance outer conductor |
≤ 5 m? |
| Insulation resistance |
≥ 5 G? |
| Voltage proof |
1.5 kVeff/50 Hz |
| Impedance |
50 ?/(75 ?) |
| Return loss: Straight style |
≥ 20 dB/3 GHz (50 ? types) |
| Return loss: Angle style |
≥ 17.7 dB / 3 GHz (50 ? types) |
| Working voltage |
≤ 500 Veff/50 Hz |
| Frequency range up to |
4 GHz |
