SYN-SVKT16GP

Guide Pin

Panel 5 pole Female, Nickel housing, silver contacts, D-size

5 pole female receptacle, solder cups, Nickel housing, silver contacts The DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding. Features & Benefits •All metal housing offers best overall RF protection and electromagnetic shielding •Duplex ground contact for excellent contact integrity between chassis and cable connector •Female contact incorporates a solder barrier to prevent solder running into the contact mating area •Larger solder contacts for easier termination •Optional connection to easily join pin1 to chassis ground •D-style housing provides installation compatibility with industry standard D mounting dimensions

Inserting Guide pin 419

Guide pin to insert female contacts only. Remove the guide pin from the inserted contact and use it for the next contact.

D-shape CAT6_A panel connector, shielded, IDC termination, black housing

D-shape CAT6_A panel connector, shielded, IDC termination, black housing

Attention! Does not intermate with CAT6 cable connector NE8MC6-MO and NKE6S* cables.
