AXE-CAT6/NEU/1303E/DRUM-CHASS

Speaker cable 8*4mm/ Neutrik NLT8 Female-Female Black/ 0,5m

Cable : Axept Pro Speaker cable Connector : Neutrik Speakon connector Accesories : Transparent Heat Shrink x 2

Grounded BNC chassis connector, feedthrough in black D-shape housing

Grounded BNC chassis connector, feedthrough in black D-shape housing Neutrik's BNC chassis connectors offer a true 75 ? design for serial and digital (HD) signals. The machined brass connector body provides an extremely rugged and non-abrasive connection over long term use and is in addition recessed and therefore well protected in a D-shape housing (audio industry standard). Features & Benefits •Gold plated cage type center contact •True 75 ? design meets the stringent HD requirements •Grounded panel mount •Standard D-shape housing - provides flush mounting and protection from demage •Color coding possible New cage type contact •Closed contact design - extremely robust •Gold plated cage type clip - best possible shielding and lowest contact resistance

BNC cable / Belden / Neutrik connector

Cable : Belden video cable 1505F black Connector : Neutrik BNC BJP9 Accesories : Transparent Heat Shrink x 2

Axept CAT6S/FTP cable black

• S/FTP Cat.6 4x2xAWG 27 LSHZ
• Outer diameter 6,2mm
• Flame retardant acc. to IEC-60332-1
• Length imprinted on strain relief
• Contacts gold-plated

Connector: RJ45 plug shielded and gold plated contacts
Boot: PVC 75A / Length imprinted
Cable: S/FTP Cat.6 4x2xAWG27 LSZH
Outer diamete: r 6.2mm
Bending radius: 5 x outer diameter
Jacket: Flame retardant acc. to IEC 60332-1
Printing: Cat.6 S/FTP 4x2xAWG27/7 PIMF ISO/IEC 11801 & EN50173-1 TIA/EIA 568.2-1
Halogen Free ***Gigabit***
general temperature range 0° up to + 60°C
withstand voltage 500V DC
