NEU-NAC3FC-HC

Aansluitsnoer 3M 3G2,5 + ST

Female Panel 419, gold cont (-ring)

The SYNTAX® SSX series, designed for professional applications and perfectly compatible with standard Socapex 419 series, is extremely robust being made of thick wall construction machined aluminium alloy, with a hard black anodized finish or black painted finish. The contacts insert is chloroprene rubber, which enables the use of removable contacts, either crimp or solder version. The unit is completely IP67 watertight when mated. Electrical safety and compliance is guaranteed by internal insulation of the shells, obtained through a safety insulating sleeve to prevent electric shock, as well as “first make last break” ground contacts. Grounding rings allow bussing of the ground contacts. Locking rings and backshells are designed for easy handling.

Power Distri 360x500x420 63/5 to 1x63/5 & 2x32/5 & 6xABL (BELGIUM/FRANCE)

V45.36.0605 Polyethyleen stapelbare verdeelkast type V45.36, horizontaal gebouwd (b x h x d = 500x360x420 mm)

o Dubbelgeïsoleerd klasse II
o Slagvast
o 4 handgrepen geïntegreerd
o 8 beschermings- en stapelhoeken
o Wcd’s en beveiligingen verzonken (beschermd) gemonteerd
o Bouwvorm kan zowel horizotaal als verticaal worden geleverd (keuze)
o Stapelbaar op de overige kasten in de nieuwe generatie V45
o Stapelmaat: 420x500
Fase indication 3x Signaallamp Neon 230V rood incl. chroomrand en o-ring IP44
Earth connection 1x Aardebout M8 groen geel met afneembare vleugelmoer
Input 1x Apparatenstekker recht CEE 400V 63A 5p 6h IP67 rood
Loop 1x Inbouwdoos recht CEE 400V 63A 5p 6h IP67 rood
Output 2x Inbouwdoos recht CEE 400V 32A 5p 6h IP44 rood
Output 6x Inbouwdoos Schuko 230V 16A 2p + penaarde IP44 blauw kleine flens
security 1x Aardlekschakelaar type PFIM 63A 4polig 30mA
security 2x Installatie automaat type PLS6 32A 3polig + Nul C-kar. 6kA
security 1x Aardlekschakelaar type PFIM 40A 4polig 30mA
security 3x Inst. Automaat type PLN6 16A 1polig + Nul C-kar. 6kA

Declaration of Conformity
