PST-IM2200-01000

D-shape CAT6_A panel connector, shielded, feedthrough, black housing

D-shape CAT6A panel connector, shielded, feedthrough, black housing Attention! Does not intermate with CAT6 cable connector NE8MC6-MO and NKE6S* cables. Features & Benefits •Ruggedized connector with CAT6A component compliance according to ISO/IEC 11801 and TIA/EIA 568-C.2 •PoE+ compliant according to 802.3at Type2 •Rugged latch lock system million fold proven •Intermateable with the existing etherCON CAT5 range •Shielded system - high noise immunity and EMI protection

Spring-loaded sealing cover

The spring-loaded cover SCCD-W shuts automatically after unplugging the cable connector and seals the chassis connectors against dust and water to IP65. The transparent cover allows you to see the protected chassis connector all the time. Suitable for: XLR D Series female XLR D Series male 1/4" Jacks D Series speakON NL2M* and NL4M* powerCON 20 A Series NAC3MPA* and NAC3MPB* powerCON TRUE1 NAC3MPX opticalCON Chassis Connectors USB NAUSB-W* HDMI NAHDMI-W* D-SUB NADB* Firewire NA1394-6-W* etherCON D Series etherCON CAT6 Chassis Connectors etherCON CAT6A Chassis Connectors BNC D Series Phono (RCA) Chassis Connectors

Panel 5 pole Female, Black housing, silver contacts, D-size

5 pole female receptacle, solder cups, black metal housing, silver contacts The DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding. Features & Benefits •All metal housing offers best overall RF protection and electromagnetic shielding •Duplex ground contact for excellent contact integrity between chassis and cable connector •Female contact incorporates a solder barrier to prevent solder running into the contact mating area •Larger solder contacts for easier termination •Optional connection to easily join pin1 to chassis ground •D-style housing provides installation compatibility with industry standard D mounting dimensions

Cable Male 5P, Black body, silver contacts

5 pole male cable connector with black metal housing and silver contacts. The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief. Features & Benefits Male connector with improved locking recess without "window", more stringent housing increases durability Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster Boot with polyurethane gland gives high protection to cable bending stresses Colored rings and boots available for coding or identification Sleek and ergonomic design - valuable and handy Rugged zinc diecast shell, longlasting and dependable Internal thread on shell is well protected against any damage Branded with unique hologram - guarantees genuine and authentic Neutrik product
