SOM-520-0051F

Cable Female 3P, Nickel body, silver contacts

3 pole female cable connector with Nickel housing and silver contacts. The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief. Features & Benefits Unique cage design of female contact for low contact resistance and high integrity Female contact incorporates a solder barrier to prevent solder running into the contact mating area Female connector with improved solid metal latch which is larger and easier to handle Additional ground spring contacts for better shell ground continuity Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster Boot with polyurethane gland gives high protection to cable bending stresses Colored rings and boots available for coding or identification Sleek and ergonomic design - valuable and handy Rugged zinc diecast shell, longlasting and dependable Internal thread on shell is well protected against any damage Branded with unique hologram - guarantees genuine and authentic Neutrik product

Cable Male 3P, Nickel body, silver contacts

The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief.

Features & Benefits
Male connector with improved locking recess without "window", more stringent housing increases durability
Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster
Boot with polyurethane gland gives high protection to cable bending stresses
Colored rings and boots available for coding or identification
Sleek and ergonomic design - valuable and handy
Rugged zinc diecast shell, longlasting and dependable
Internal thread on shell is well protected against any damage
Branded with unique hologram - guarantees genuine and authentic Neutrik product

Declaration of Conformity

SC-Monolith 1 compact; power: 3 x 1,50 mm²; DMX: 2 x 0,14 mm²; PVC Ø 9,50 mm; black

Technical Data: - Name: SC-Monolith 1 compact - Properties: OFC oxygen free copper - Properties: Digital 110 Ω AES / EBU - Properties: Analog - Application area: Studio / Broadcast - Application area: Installation - Application area: Mobile outdoor / indoor - Application area: Stage / live - Application: DMX & Power - Colour: black - Colour detailed: black - Signal transmission: symmetrical - Jacket material: PVC - Jacket Ø: 9,5 mm - Jacket Ø (AES/EBU, DMX): 3 mm - Number of Channels (power): 1 - Number of Channels (AES/EBU, DMX): 1 - Inner conductor (power): 3 - Inner conductor (AES/EBU, DMX): 2 - Inner conductor (power): 1,5 mm² - Inner conductor (AES/EBU, DMX): 0,14 mm² - Inner conductor Ø (power): 1,38 mm - AWG (power): 15 - AWG (AES/EBU, DMX): 25 - Shielding (audio): Copper spiral, tin-plated - Shielding (AES/EBU, DMX): Copper spiral, tin-plated - Copper strands (power): 28 - Copper strands (AES/EBU, DMX): 36 - Copper strand Ø (power): 0,25 mm - Copper strand Ø (AES/EBU, DMX): 0,07 mm - Conductor insulation material (AES/EBU, DMX): PVC - Conductor insulation Ø (power): 2,8 mm - Conductor insulation Ø (AES/EBU, DMX): 1,15 mm - Weight per 1 m: 144 g - UV-resistant: yes - Fire load per m: 0,54 kWh - Style variant: round - Shielding factor: 90 % - Packing: bulk stock - Temperature min.: -30 °C - Temperature max.: 70 °C - Width: 9,5 mm - Height: 9,5 mm - Capac. cond./cond. per 1 m (audio): 52 pF - Capac. cond./cond. per 1 m (AES/EBU, DMX): 52 pF - Capac. cond./shield. per 1 m (audio): 89 pF - Capac. cond./shield. per 1 m (AES/EBU, DMX): 89 pF - Surge impedance (audio): 110 Ω - Surge impedance (AES/EBU, DMX): 110 Ω - Insulation resist. per 1 km (audio): 0,1 GΩ - Insulation resist. per 1 km (AES/EBU, DMX): 0,1 GΩ

19" LED Racklite with 2 Goosenecks

Product type 19" Rack Accessories Connection type XLR connector Type 19" / 1 U Operating voltage 12 V DC Lamp LED Colour of lamp white Power input Low-voltage socket Housing material metal Colour Black Accessories (included) power supply Width 485 mm Height 44 mm Depth 49 mm Weight 0,694 kg Other features Dimmer , LEDS on 2 x 30 cm gooseneck , white and blue light selectable
